IntegraRack IR-30 Solar Panel Ground Mount Bracket – 30 Degree Angle (Individual Frame)

SKU: IR-30RF1030

The IntegraRack IR-30 is a scalable, DIY-friendly racking system for any size solar array.  These racks can be secured with innovative anchoring systems such as EarthBallast, AnchorSpike, Concrete anchors,  or even concrete curb stops or low-profile water tanks – installation has never been easier!

  • No earth augers, concrete piles, or post ponding required
  • Each frame is laser-cut from high-grade aluminum, and secures to panels with stainless-steel hardware
  • Compatible with any full-size (300W+) solar module without any modification to the module
  • Holds the panels at a 30-degree angle.  Also available in 15 degree45 degree, adjustable and seasonably adjustable versions
  • Ships in a compact box via ground parcel transport – no need for expensive freight deliveries
  • When purchasing these mount, you will require one more mount then the solar panels you need (Ex: 4 panels, 5 mounts)
  • The price shown is for one individual frame

$109.99

Log in to check member price

9 in stock (Accepting backorders for additional units.)

Description

IntegraRack IR-30 BallastRack™ Solar Module Racking System

The IR-30 is the fastest and easiest ground mounting system available, and allows for modules of any size to be racked at a fixed 30° for optimal year-round energy production. This system can be mounted almost anywhere with its four available mounting options, and is strong enough to withstand wind speeds of up to 150 miles per hour. The IR-30 is also the lowest cost per kW option on the market, with only one IR-30 Frame needed per solar module after starting the row, and no pouring of concrete footings required.

– Fast Assembly & Install

  • 2 minute assembly per IR-30 Frame
  • Installation as fast as 10 minutes per module
  • No earth augers, no concrete, and no post ponding required
  • Only one main frame component is required between each solar module to complete entire ground mount system

– Universal Mounting

Four Mounting Options:

  • IR EarthBallast™ Kit – Uses fast setting epoxy to adhere geotextile material to IR-30 Frames and earth fill over for a fast ballasted system
  • IR AnchorSpike™ Kit – Mount IR-30 Frames by clamping the base tubes around specially designed anchor spikes that provide easy off the ground leveling
  • Concrete Lag Bolt Kit – Bolt the IR-30 Frames directly to any concrete surface (concrete pad, footings, or patios)
  • Base Ballasting – Hold IR-30 Frames in place using flat water tanks or concrete curb stops

– Most Cost Effective Ground Mounted Solar System

  • One of the lowest cost per kW ground mount racking systems on the market
  • Traditional ground mount solar racking systems take 6x longer to install and are much more labor intensive

– High-Strength Engineered & Tested

  • Extensively engineered and outdoor lab tested with simulated real world wind and snow load conditions
  • Build entirely from aircraft grade 6061 T6 aluminum with stainless steel mounting brackets
  • Capable of withstanding up to wind loads of up to 150 mph and snow loads of up to 100 pounds per sq ft (click manufacturers resources link below for detailed Datasheets)
  • Strong, simple “U” shaped design provides amazing strength

– Unprecedented Versatility

  • Fixed 30° angle for optimal year-round energy production and excellent snow shedding capabilities
  • Up to 2 feet of ground clearance
  • Adjustable solar module height
  • Portrait solar module mounting for easy wiring
  • The Base Tubes of each IR-30 Frame are designed to clamp around and bite into IR AnchorSpikes or concrete stakes for easy leveling and increased hold down strength.

Additional Components Required For Some Mounting Configurations

1 Inch EMT/Conduit Pipe (required for certain mounting options).  1 inch EMT adds racking strength and helps with positioning for module spacing.  10 foot long Conduit Pipes can be sourced locally (Home Depot, Lowes, Electrical Hardware Store, Etc.).

Recommended Accessories:

Additional information

Dimensions 48 × 5 × 5 in
