BigBattery 48V HUSKY 2 INV 100Ah 5.12kWh LiFePO4 Battery for RV, Van and Marine, Self-Heating, IP65, Closed-Loop CAN/RS485
SKU: SKY-48051-G2-INV



Log in to check member price and detailed stock information.
| Need more than what's available? Tell us what you need and we can source it for you. |
Product Summary
The BigBattery HUSKY 2 INV is a 48V LiFePO4 house battery for RVs, vans, boats and off-grid cabins, with 5.12kWh in a 100 lb IP65 case that bolts to a wall or floor. It warms itself before charging in the cold, talks closed-loop with Victron MultiPlus-II and EG4 inverters, and parallels up to 16 units when you need more storage.
Specifications:
-
51.2V nominal for 48V systems, 5.12kWh (100Ah) of LiFePO4 storage
-
100 lb (45.4 kg) and 9.8×18.1×12.6in (249×460×320mm), with handles, L-brackets and a 2 AWG cable pair included
-
IP65 (NEMA 4X) vibration-resistant case with built-in fire suppression and an LED state-of-charge display
-
100A continuous charge and discharge, 150A peak discharge for 3 seconds
-
Built-in heater; charges from -4°F to 113°F and discharges from -4°F to 122°F
-
Closed-loop CAN or RS485 on two RJ45 ports, plus Bluetooth app monitoring
-
Up to 16 batteries in parallel (81.92kWh); parallel only, no series connection
-
Rated for 4,000 to 6,000 cycles at 80% depth of discharge

Current Connected is YOUR BigBattery product specialist
About the BigBattery 48V HUSKY 2 INV Battery
A 48V house bank in a case you can carry. The BigBattery HUSKY 2 INV packs 5.12kWh of LiFePO4 into a 100 lb box under 10 inches tall, sealed to IP65 and NEMA 4X, so it fits an RV storage bay, a van build or a dry compartment on a boat where a floor-standing cabinet never would.
BigBattery features the HUSKY 2 INV in its RV and van systems for larger motorhome and camper builds. Running the house system at 48V keeps current low: a 3,000W load draws roughly 60A at 48V versus about 235A at 12V, so cable runs get smaller and cooler. Start with one battery and add more in parallel as the build grows.
48V RV and Van Battery for Victron MultiPlus-II Systems
BigBattery pairs the HUSKY 2 INV with Victron in its own mobile kits: one battery with a MultiPlus-II 48/3000 and a Cerbo GX, or two batteries with a MultiPlus-II 48/5000. The battery talks to the GX device over CAN, so the inverter-charger takes its charge limits and state of charge straight from the BMS instead of estimating from voltage. You set the protocol in the BigBattery HUSKY 2 app, then power-cycle the battery.
Each battery delivers 100A continuous, and BigBattery recommends about 4,000W of continuous load per battery. The 150A, 3-second peak gives the inverter room for starting surges from an air conditioner, an air compressor or a welder.
Our Victron 48V Mobile/RV Kit offers the HUSKY 2 INV as a battery option alongside MultiPlus-II inverter-chargers and a Cerbo GX, so you can build the whole system in one order.
Our team is happy to help with sizing.
Cold-Weather Charging With IP65 Protection on the Road and on the Water
When a charger connects below freezing, the built-in heater warms the cells and charging starts once they pass 32°F (0°C), down to -4°F (-20°C) ambient. Discharge runs from -4°F to 122°F, and BigBattery puts the best range for long life at 59°F to 95°F.
The IP65 rating keeps out dust and water spray, NEMA 4X adds corrosion resistance, and BigBattery describes the enclosure as vibration-resistant. Built-in fire-extinguishing modules sit inside as a backstop to the BMS, which shuts the battery down at low voltage, guards against overcurrent and over-temperature, balances the cells, and flags faults on the LED display.
Off-Grid Cabin and Home Backup With EG4 Inverters
The same battery anchors a cabin or backup system. BigBattery lists the EG4 6000XP and 12000XP for closed-loop operation and bundles the 6000XP with two HUSKY 2 batteries, in line with its 4,000W-per-battery recommendation. Pair at least two with an EG4 6000XP, then keep adding batteries, up to 16 for 81.92kWh.
Mounting and Wiring the HUSKY 2
Remove the handles, then attach the L-brackets to the left, right or bottom edge of the case and bolt the battery to a wall or floor. In a parallel bank, connect all positives together and all negatives together with ring-terminal cables on the M8 terminals, and bring every battery to the same voltage before you connect them.
Set the battery wired to the inverter as Module ID 1 in the app, give the followers IDs 2, 3 and up, and daisy-chain communication cables between them.
Main battery protection belongs on a Class T fuse sized to your inverter cable, and our Class T fuses from 225A to 400A suit the main run on a multi-battery bank.
For runs longer than the included 3 ft cables, our custom battery cables are made to order in 6 AWG to 4/0 AWG at the exact length you need.
Recommended Accessories
Frequently Asked Questions
Choose a lithium or user-defined profile with 57V bulk and absorption, no absorption time and equalize off, and set the inverter's low-battery shutdown to 50.8V. BigBattery lists 55V for charge controllers that require a float value, though the battery itself doesn't need float. Keep charge and discharge current at or below 100A per battery.
BigBattery publishes CE and UN38.3 certificates for the 48V HUSKY 2, and it doesn't list a UL 1973 battery listing or a UL 9540 system listing. That makes it a fit for off-grid systems and installs where your AHJ (Authority Having Jurisdiction) doesn't call for UL 9540 equipment. If the system needs a permit or a utility interconnection, confirm with your AHJ before you buy.
BigBattery's manual lists RVs and boats among the HUSKY 2's applications, and its spec sheet states the battery isn't meant for mobility systems. Use it as the house battery that runs your inverter and appliances, not as the battery that drives a golf cart, UTV or other vehicle.
The INV is the inverter-communication version, with closed-loop CAN and RS485, 100A continuous and 150A for 3 seconds. BigBattery's HUSKY 2 PWR uses the same 5.12kWh case with 160A continuous and 350A for 10 seconds, but its spec sheet states it can't communicate with any inverter. For an RV, van, boat or cabin system that runs closed loop with your inverter, the INV is the one to buy.
Divide 5.12kWh by your average load and allow about 10% for inverter losses. A van or RV averaging 300W runs roughly 15 hours on a full charge, and a 1kW load runs about 4.5 hours. For daily cycling at 80% depth of discharge, plan on about 4kWh per battery per day.
