Description
The Littelfuse Mega fuse provides high-current circuit protection from 40A through 500A using patented Diffusion Pill Technology. This “Slo-Blo” design handles the surge currents that occur when inverters start up or batteries begin charging, without nuisance tripping during normal operation.
Rated at 70VDC maximum, these fuses work perfectly with all common battery voltages – 12V, 24V, 36V, 48V, and 60V systems. The bolt-down design mounts securely onto M8 studs in your fuse holder or distribution block. Just torque the mounting hardware to 25Nm (about 18 ft-lbs) for a solid, low-resistance connection that won’t overheat under load.
These are genuine Littelfuse fuses – the same ones used as original equipment by respected automakers. The color-coded housings make it easy to identify amperage ratings at a glance during installation or troubleshooting. They’re built to handle temperature extremes from -40°F to +220°F, so they’ll work reliably whether mounted in a hot battery compartment or cold outdoor enclosure.
Perfect for protecting the main connections between your battery bank and inverter, charge controller outputs, or any high-current DC circuit in your solar system. The time-delay feature is especially important for inverter protection – it allows the brief surge when your inverter powers up heavy loads, while still protecting against dangerous overcurrent situations. For continuous loads, use fuses rated 40A-250A. The 300A-500A sizes are designed for short-circuit protection only.
