Victron SmartSolar Charge Controller – MPPT RS 450V 100A and 200A

SKU: Various
Victron SmartSolar Charge Controller MPPT RS 450/100
Victron SmartSolar Charge Controller MPPT RS 450/100
Victron SmartSolar Charge Controller MPPT RS 450/100
Victron SmartSolar Charge Controller MPPT RS 450/100 Internal view
Victron SmartSolar Charge Controller MPPT RS 450/100 Bottom
Victron SmartSolar Charge Controller MPPT RS 450/100
Victron SmartSolar Charge Controller MPPT RS 450/100
Victron SmartSolar Charge Controller MPPT RS 450/100
Victron SmartSolar Charge Controller MPPT RS 450/100 Internal view
Victron SmartSolar Charge Controller MPPT RS 450/100 Bottom
DatasheetManualDimensions

-

Description

The SmartSolar RS solar charge controller connects to a PV array of between 80 and 450 Volt Voc and will efficiently charge your 48V battery bank with either 100A or 200A.  The charge settings are fully programmable and can be set up for different battery chemistries, like lead-acid, lithium and more.

Setup and monitor with VictronConnect

The SmartSolar RS charge controller can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, historical data and trends.

Daisy Chain Additional Units

The SmartSolar RS charge controller is equipped with VE.Can bus ports. This allows for communication with additional SmartSolar RS & VE.Can MPPT units. The additional units are simply “daisy chained” to each other with an RJ45 cable.
When connected to each other, all individual charge controllers, will synchronise their charge stages. They can also send their data, via the same cable, for monitoring to a GX device (such as the Cerbo GX).

Remote Monitoring and Control

If the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your SmartSolar RS charge controllers. If your installation is connected to a GX device and the internet, Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; for free. For remote installations – even when there is no internet connection nearby – you may be able to monitor your MPPT by connecting the GlobalLink 520.

SmartSolar Display

The SmartSolar RS charge controller is equipped with a display on the front panel. The display reads battery volts, charge current and voltages from both array’s individually including instantaneous and total figures and unit status including any possible error codes.

I/O Connections

The SmartSolar RS charge controller is equipped with a programmable relay and options for remote temperature and voltage sensing. The remote input can accept the Victron smallBMS and other types of BMS with allow-to-charge signals.

Recommended Accessories:

Additional information

Weight 22.40 lbs
Dimensions 21 × 16 × 9 in

Why Choose Victron?

Victron Energy is a globally recognized leader in technical innovation, renowned for producing high-quality, reliable products crafted with meticulous attention and precision, ensuring superior performance and durability.

Established in the Netherlands in 1975, Victron Energy manufactures dependable off-grid battery inverter chargers and affordable solar controllers. In the automotive, RV, and boating market, they stand out as one of the top-quality manufacturers through their commitment to continuous improvement and development of their products. Victron frequently introduces innovative products and enhanced hardware/software through free updates, always staying on the forefront of independent energy systems.

With over 45 years of expertise in designing robust off-grid systems, Victron excels in delivering solutions that prioritize reliability. Their commitment is reinforced by cutting-edge software, user-friendly monitoring apps, a network of skilled professionals, and widespread repair centers, ensuring unparalleled support for their products. Victron equipment surpasses performance expectations and boasts an extended life cycle that goes beyond industry standards. They back their products with a 5-year warranty and efficient repair policies, providing you with the assurance and protection necessary for your investments.

Choose Victron Energy for reliable, innovative, and long-term power solutions. Experience the difference that their industry-leading products and expertise can make for your energy needs.
