Product Summary
Build a complete EG4 power system on one page, starting with the inverter. Then add an EG4 battery bank, solar panels, and IntegraRack ground mounting as you need them, and watch your total update as you go.
What You Can Configure:
-
Inverter: EG4 FlexBOSS18, FlexBOSS21, 18kPV, 12000XP, or 6000XP
-
Battery bank (optional): EG4 WallMount and server rack options
-
Solar panels (optional)
-
Ground mount and mounting method (optional): IntegraRack BallastRack frames with EarthBallast, EarthScrew, or slab mounting
Configure Your System
Inverter
RequiredChoose Inverter*
Product Details
EG4 FlexBOSS18 48V Hybrid All-In-One Inverter, 10kW AC Output, 18kW Solar Input, NEMA 4X, UL 1741 & UL 9540
Specifications:
- Continuous output power: 10kW (increases to 13kW with solar input)
- Two MPPTs, up to 600Vdc max
- Complete rapid shut down & RSD transmitter
- AUX terminals for automatic gen start
- 60W zero load consumption
- 208A battery charger
- Built in 90A transfer switch
- Enclosure rating: NEMA 4X
- UL 9540 with EG4 WallMount All Weather and WallMount Indoor 280Ah batteries
- Dimensions (H×W×D): 30.43×22.28×11.22in
- Weight: 115lbs
| Need more than what's available? Tell us what you need and we can source it for you. |
Battery Bank
OptionalEG4 batteries pair well with any EG4 inverter. The 280Ah and 314Ah WallMount batteries support up to 200A continuous each, whereas the server rack battery options can only support 100A each, so make sure to add at least enough battery capacity to meet the demand of all inverters connected.
Max. amperage each inverter demands from batteries:
- 6000XP: 140A
- 12000XP: 250A
- 12kPV: 167A
- 18kPV: 250A
- FlexBOSS18: 208A
- FlexBOSS21: 250A
Choose Battery Bank
Product Details
EG4 Electronics 48V WallMount 314Ah Indoor Battery, 16kWh Lithium Battery Storage for Residential Energy Systems, UL 1973
EG4’s 314Ah Indoor WallMount battery provides up to 16kWh of energy storage for a residential or commercial alternative energy system that is off-grid or grid-tied.
Specifications:
- Capacity: 16kWh
- Recommended charge/discharge current: 157A
- Max. continuous charge/discharge current: 157/200A
- Peak discharge current: 250A for 3s
- Communication options: RS485 and CAN ports
- Rated for 10,000 cycles @ 0.5C or 10 years
- Certifications: UL 1973, UL 9540 (with FlexBOSS18 and FlexBOSS21)
- Weight: 314lbs
- Dimensions (H×W×D): 36.4×18.1×9.6in
| Need more than what's available? Tell us what you need and we can source it for you. |
Solar Panels
OptionalChoose Solar Panels
Product Details
Talesun BIPRO TP7G54M(H)-415-BB 415W Black on Transparent 108 Half-Cell Bifacial Solar Panel Pallet of 36, IP68
The Talesun BIPRO 415W bifacial panels are designed with monocrystalline bifacial PERC cells, which make them ideal for rooftop or ground mount installations in snowy geographies or with uneven shading. The Anti-PID (Potential Induced Degradation) performance is two times the industry standard, for long lasting production.
Specifications:
- Wattage: 415W
- Open-Circuit Voltage (Voc): 37.75V
- Short Circuit Current (Isc): 14.02A
- Operating Voltage (Vmp): 31.64V
- Operating Current (Imp): 13.13A
- 108 Cells (Split cell technology)
- Monocrystalline, bifacial
- Efficiency: 21.25%
- Temperature Rating: -40-185°F
- Mechanical Load: Front side 5400Pa, Back side 2400Pa
- Certifications: UL 61730
- Weight: 47.4lbs
- Dimensions (H×W×D): 67.8×44.65×1.18in
Each unit is a full pallet of 36 panels.
| Need more than what's available? Tell us what you need and we can source it for you. |
Kit Summary
| Component | Selection | Qty | Subtotal |
|---|---|---|---|
| — | $0.00 | ||
| Excluded | Not included | 0 | — |
| Excluded | Not included | 0 | — |
| Total | $0.00 | ||
Finish choosing your options above to continue.
