Sol-Ark 8kW All-In-One 48V Hybrid Inverter

SKU: 8k-2P

The Sol-Ark 8k Hybrid Inverter allows for up to 11,000W of solar power with a 63A transfer switch. With 2 built-in MPPTs, this inverter can take in 500 VDC and a startup voltage of 125 VDC. With a NEMA 3R Certification, this inverter is ready to install out of the box.


  • Max Allowed PV Power: 11,000W
  • Max DC Voltage (Voc): 500V @ 18A
  • Startup Voltage: 125V
  • Number of MPPTs: 2
  • Connections: 120/240/208V Split-Phase
  • Zero Load Consumption: 60W
  • 63A Feedthrough for critical loads
  • Weight: 78 lbs.
  • Dimensions (HxWxD): 30 x 18.3 x 10 inches
  • NEMA 3R Certified

1 in stock




The Sol-Ark 8kW comes with a 500V DC solar input, allowing for up to 11,000W of solar. With different modes of operation, this inverter allows for both off-grid and on-grid applications. It also comes with the ability to add batteries at any time. Being able to work with FLA, AGMl, or Lithium Batteries, the Sol-Ark has no trouble communicating with batteries that need closed-loop communication. With the Sol-Ark, there is no need for additional breakers, fuses, combiner boxes, and rapid shutdown equipment, as it is all built into the system.


  • 63A built-in transfer switch
  • Capable of different modes, including grid sell, limited power to the home, limited power to load, and time of use
  • Able to turn on loads when excess power is available
  • NEMA 3R rated, allowing outdoor installation
  • Has Closed-Loop Communication, able to work with any LiFePO4 batteries requiring communication
  • It has AC and DC coupling, allowing for a combination of DC-coupled and AC-coupled solar panels
  • Built-in Rapid shutdown and emergency stop
  • Built-in remote monitoring system


  • Off-grid housing, on-grid housing
  • 48V Lithium or Lead Acid charging

Recommended Accessories:

Additional information

Weight 97 lbs
Dimensions 35 × 23 × 14 in
