SOK Battery 206Ah 12V LiFePO4 Battery | Solar Battery
7-Year Manufacturer Warranty + Current Connected 3 Year Extended Warranty* (10 Years Total)!
The SOK 206ah Lithium Deep Cycle battery is one of the best selling batteries for a reason, bang for your buck. No fluff, this battery does what you want and will last a ridiculous 4000-8000 cycles! Perfect for Vanlife, RV’s, Off-grid cabins and more.
4000~8000 Cycles Life Span, Maintenance Free. Drop-In Replacement. Detachable Cover & Replaceable BMS and Cells!
Connect in series for 24V or 36V or 48V Battery Bank, or Connect in Parallel for Larger Capacity.
Smart battery management system with low temperature cut off protection, even in very cold locations so you don’t have to worry about moving the battery to your bedroom!
Connecting in 24v or 48v Battery Banks? We recommend this accessory.
SOK Battery 12V LiFePO4 Spec Sheet:
|Run time at 20A Load
||≤28mΩ @ 50% SOC
||< 3% per month
|Max Batteries in Series
||4 (48v Nominal)
|Max Continuous Discharge Current
|Peak Discharge Current
||200A (3 Seconds, automatic shutdown)
|BMS Short Circuit Cut-off Current
|Recommended external Low-voltage disconnect
|BMS Low-Voltage disconnect
|BMS Low-Voltage recover
|BMS Short Circuit Protection
|Recommended Charge Current
|Max Charge Current
|Recommended charge voltage
|BMS Charge Cut-off voltage
|BMS Charge Cut-off recover
||-22°F – 140°F
||32°F – 140°F
||-22°F – 140°F
|Footprint Dimensions (LxW)
||10.6 x 7.9 Inches
||11.9 x 7.9 Inches
||11.42 x 7.87 Inches
|Overall Dimensions Including Handles & Terminals (LxWxH)
||10.6 x 7.9 x 9.1
||12.9 x 7.9 x 12.3
||13.38 x 9 x 11.02
|Terminal Thread Type
|Third Party Testing
Charger & Inverter Settings
General settings that apply to most equipment. For Victron BlueSmart Chargers, please refer to the BlueSmart product listing page for exact parameters.
Multiply voltages by 2 for 24v systems and by 4 for 48v systems.
Charge Current (Per battery): 40a Preferred (50a Maximum)
Absorption Voltage: 14.6v preferred (14.4 Minimum)
Float Voltage: 13.8v preferred (13.6 Minimum)
Low Voltage Disconnect (LVD): 11v
MUST BE DISABLED. SET DURATION TO 0 MINUTES.
If you can, we recommend setting the equalization voltage to 14.6v. With this set at 14.6, if an equalization is somehow triggered, you will not damage your battery.
Victron Settings For SmartShunt & BMV-712 / SOK Battery
Battery Capacity: Varies depending on system.
Charged Voltage: 13.8 (*2 for 24v & *4 for 48v Systems)
Discharge Floor: 10%
Tail Current: 2.00%
Charged Detection Time: 3m
Peukert Exponent: 1.05
Charge Efficiency Factor: 98%
Current Threshold: 0.10a
Time-to-go averaging Period: 3m
Battery Starts Synchronized: Disabled (NOTE: you will need to fully charge your battery to sync up SOC%)
State of Charge: 30% (NOTE: Set this to 30% with brand new, untouched batteries. They ship at 30% SOC%.)
Comment on Discharge floor:
Let’s say you setting this at 10%; when you get to 10%, the Smartshunt will indicate 10% remaining and 0 minutes until empty. If you choose to fully discharge your battery (not recommended) then set this to 0%. If you want to be more conservative on your time remaining, then set this to 20%
Settings for Victron MPPT Charge Controllers:
Battery Voltage: Set depending on system, normally 12v.
Max Charge Current: OK to set as high as desired, but no more than 50a per battery
Battery Preset: User Defined
Expert Mode: ON
Absorption Voltage: 14.6v
Float Voltage: 13.8v
Equalization Voltage: 14.6v
Rebulk Voltage Offset: 0.40v
Absorption Duration: Fixed
Absorption Time: 15 Minutes (This allows for proper cell balancing)
Tail Current: Disabled
Equalize Current: 0% (For safety we don’t want equalization at all.)
Automatic Equalization: Disabled
Equalize Stop Mode: Automatic (On voltage)
Maximum Equalize duration: 0 Minutes
Manual equalization: DO NOT CLICK START
Temperature Compensation: Disabled
Low Temperature Cutoff: Disabled (unless you add a temp sensor, the BMS has this protection built in)
Settings for Renogy Charge Controller (Wanderer, etc.)
IMPORTANT: For battery type, select “USER”
High Voltage Disconnect: 15.0
Charge Limit Voltage: 14.6v
Equalize Charge Voltage: 14.4
Boost Charge Voltage: 14.6v
Float Charge Voltage: 13.8v
Boost Charge Return Voltage: 13.4
Over Discharge Return Voltage: 12.0v
Low voltage Alarm:11.8v
Over Discharge Voltage: 11.0v
Discharge Limit Voltage: 10.5
Over Discharge Delay Time: 5 Seconds
Equalize Charge Time: 0
Boost Charge Time: 15 Minutes
Equalize Charge Interval: 0
Temperature Compensation: 0
Can you ship to Hawaii & Alaska?
Yes, however it is subject to our Alaska / Hawaii shipping policy.
Does this battery have Low-Temperature protection?
Yes! The battery will prevent charging below 0°C in order to protect the cells while continuing to allow discharging. If you need to charge the battery in sub-zero temperatures, we recommend adding a heating pad that can be turned on to warm up the battery prior to charging.
What temperatures do the batteries need to be brought out of the cold?
The lowest safe storage temperature is -22°F, so any temperatures below this, you should bring them inside or add a heating pad of some sort, but keep in mind if a heating pad runs out of power and the battery falls below -22°F, damage may occur.
Does this fit into a standard “group size” battery box?
No, these batteries are just a bit too big to fit into your standard battery boxes. Many of our customers have had great luck installing into tool boxes or similar enclosures that provide protection from the elements. The metal-cased batteries are not waterproof. The Plastic 206ah battery can be installed in wet environments such as the tongue of trailers, in which case they fit great with the factory battery boxes removed.
Can I use my old Lead-Acid Charger?
This is not a simple “yes” or “no” question. If your charger has an equalize feature that exceeds 14.6v, then it absolutely cannot be used. The maximum charge current of a SOK Battery is 50 amps, so your total combined charge current may not exceed 50a * [number of parallel batteries]. You must also check the output voltages of the charger throughout a full charge cycle; if they exceed 14.6v they cannot be used. It is optimal to have an absorption voltage of 14.4v and a float voltage of 13.6. The battery isn’t totally picky regarding the float voltage, but we recommend 13.6 for optimal lifepsan. If you are limited on parameters, it is best to be on the lower-voltage side – you may sacrifice a bit of capacity, but longevity will increase significantly. Additionally, if your batteries get to a very low SOC, then they can draw more power from your charger than it is designed for leading to nuisance blown fuses & circuit breakers.
Can the battery be installed on its side?
Absolutely! With no acid or venting, this battery can be installed in any configuration except for upside-down (terminals facing down).
Why do you charge for shipping when buying from SOK directly has free shipping?
We are a small mom & pop business, there are 3 of us here running this operation.
We put out a lot of money to SOK battery to buy the product, then wait a long time for transport by sea. Shipping to you is expensive, and we already cover more than ½ the cost of shipping, but anything more would make it unrealistic to carry the product at all.
SOK is a much bigger corporation that can afford to spend their profits on shipping, but that is not the case for us.
The difference is, we are nimble enough to provide excellent customer support, extended warranty (beyond what SOK offers) and, we have a phone number [(208) 656-2700], you can ring us and talk to a real person that speaks English. We ensure you are taken care of regardless of the circumstance.
What is the warranty policy, and how do I get any problems with the product fixed?
These batteries have a 7 year manufacturer warranty. If you have any issues with the product, please call us. Our team is on standby ready to help you. Our business relies on happy customers with working solutions, so if the battery is not working for you it is our job to provide the necessary after-sales support to turn a product into a solution. We have the faith and have done the testing to know these batteries will last a long time, and we are here for you through the entire duration of ownership.
Do I need to register for the extended warranty?
No, we track all orders as they are placed through our website database (which is regularly backed up). If you have any issues we will look up your order. If you wish to make it easier for us, have your order number handy. If not, we can certainly look your order up by name.
